TEE RIDOTTI SENZA SALDATURA

ASME B16.9

tee-rid

TEE RIDOTTI SENZA SALDATURA

ASME B16.9

D.E. POLLICI

D.E. INCHES

Ø EST. MM X SPESS. MM

OUTS. DIAM. MM X THICKN MM

Sp X Sp Mm

Thck X Thck Mm

SCH

C

M

PESO TEORICO

THEORICAL WEIGHT KG

3/4" x 1/2"

26,70 x 21,30

2,87 x 2,77

Std

29

29

0,16

26,70 x 21,30

3,91 x 3,73

Xs

0,20

1" x 1/2"

33,40 x 21,30

3,38 x 2,77

Std

38

38

0,30

33,40 x 21,30

4,55 x 3,73

Xs

0,37

1" x 3/4"

33,40 x 26,70

3,38 x 2,87

Std

0,30

33,40 x 26,70

4,55 x 3,91

Xs

0,38

1 1/4" x 1/2"

42,40 x 21,30

3,56 x 2,77

Std

48

48

0,54

42,40 x 21,30

4,85 x 3,73

Xs

0,68

1 1/4" x 3/4"

42,60 x 26,70

3,56 x 2,87

Std

0,54

42,60 x 26,70

4,85 x 3,91

Xs

0,68

1 1/4" x 1"

42,60 x 33,410

3,56 x 3,38

Std

0,54

42,60 x 33,410

4,85 x 4,55

Xs

0,69

1 1/2" x 3/4"

48,30 x 26,70

3,68 x 2,87

Std

57

57

0,77

48,30 x 26,70

5,08 x 3,91

Xs

0,98

1 1/2" x 1"

48,30 x 33,40

3,68 x 3,38

Std

0,77

48,30 x 33,40

5,08 x 4,55

Xs

1,02

1 1/2" x 1 1/4"

48,30 x 42,40

3,68 x 3,56

Std

0,77

48,30 x 42,40

5,08 x 4,85

Xs

1,02

2" x 1"

60,30 x 33,40

3,91 x 3,38

Std

64

51

0,98

60,30 x 33,40

5,54 x 4,55

Xs

1,32

2" x 1 1/4"

60,30 x 42,40

3,91 x 3,56

Std

57

1,04

60,30 x 42,40

5,54 x 4,85

Xs

1,44

2" x 1 1/2"

60,30 x 48,30

3,91 x 3,68

Std

60

1,06

60,30 x 48,30

5,54 x 5,08

Xs

1,44

2 1/2" x 1 1/4"

73,10 x 42,40

5,16 x 3,56

Std

76

64

1,72

73,10 x 42,40

7,01 x 4,85

Xs

2,14

2 1/2" x 1 1/2"

73,10 x 48,30

5,16 x 3,68

Std

67

1,72

73,10 x 48,30

7,01 x 5,08

Xs

2,14

2 1/2" x 2"

73,10 x 60,30

5,16 x 3,91

Std

70

1,72

73,10 x 60,30

7,01 x 5,54

Xs

2,24

3" x 1"

88,90 x 33,40

5,49 x 3,38

Std

86

70

2,45

88,90 x 33,40

7,62 x 4,55

Xs

2,80

3" x 1 1/4"

88,90 x 42,40

5,49 x 3,56

Std

70

2,45

88,90 x 42,40

7,62 x 4,85

Xs

2,80

3" x 1 1/2"

88,90 x 48,30

5,49 x 3,68

Std

73

2,48

88,90 x 48,30

7,62 x 5,08

Xs

3,05

3" x 2"

88,90 x 60,30

5,49 x 3,91

Std

76

2,48

88,90 x 60,30

7,62 x 5,54

Xs

3,09

3" x 2 1/2"

88,90 x 73,10

5,49 x 5,16

Std

83

2,91

88,90 x 73,10

7,62 x 7,01

Xs

3,50

4" x 2"

114,30 x 60,30

6,02x x60,30

Std

105

89

4,12

114,30 x 60,30

8,56 x 4,54

Xs

5,08

4" x 2 1/2"

114,30 x 73,10

6,02 x 5,16

Std

95

4,48

114,30 x 73,10

8,56 x 7,01

Xs

5,96

4" x 3"

114,30 x 88,90

6,02 x 5,49

Std

98

4,56

114,30 x 88,90

8,56 x 76,62

Xs

6,13

5" x 3"

141,30 x 88,90

6,55 x 5,49

Std

124

111

7,60

141,30 x 88,90

9,53 x 7,62

Xs

8,85

5" x 4"

141,30 x 114,30

6,55 x 6,02

Std

117

7,10

141,30 x 114,30

9,53 x 8,56

Xs

9,90

6" x 3"

168,30 x 88,90

7,11 x 5,49

Std

143

124

10,22

168,30 x 88,90

10,97 x 7,62

Xs

13,33

6" x 4"

168,30 x 114,30

7,11 x 6,02

Std

130

10,25

168,30 x 114,30

10,97 x 8,56

Xs

14,26

6" x 5"

168,30 x 141,30

7,11 x 6,55

Std

137

11,13

168,30 x 141,30

10,97 x 9,53

Xs

15,04

8" x 4"

219,10 x 114,30

8,18 x 6,02

Std

178

156

16,77

219,10 x 114,30

12,70 x 8,56

Xs

24,59

8" x 5"

219,10 x 141,30

8,18 x 6,55

Std

162

17,36

219,10 x 141,30

12,70 x 9,53

Xs

24,59

8" x 6"

219,10 x 168,00

8,18 x 7,11

Std

168

17,96

219,10 x 168,00

12,70 x 10,97

Xs

28,27

10" x 4"

273,00 x 114,30

9,27 x 6,02

Std

216

184

26,93

273,00 x 114,30

12,70 x 8,56

Xs

35,11

10" x 6"

273,00 x 168,00

9,27 x 7,11

Std

194

26,93

273,00 x 168,00

12,70 x 10,97

Xs

35,11

10" x 8"

273,00 x 219,10

9,27 x 8,18

Std

203

28,35

273,00 x 219,10

12,70 x 12,70

Xs

36,97

12" x 6"

323,90 x 168,30

9,53 x 7,11

Std

254

219

40,50

323,90 x 168,30

12,70 x 10,97

Xs

75,20

12" x 8"

323,90 x 219,10

7,53 x 8,18

Std

229

40,50

323,90 x 219,10

12,70 x 12,70

Xs

75,20

12" x 10"

323,90 x 273,00

9,53 x 9,27

Std

241

43,00

323,90 x 273,00

12,70 x 12,70

Xs

75,20

14" x 10"

355,60 x 273,00

9,53 x 9,27

Std

279

257

87,84

355,60 x 273,00

12,70 x 12,70

Xs

98,60

14" x 12"

355,60 x 323,90

9,53 x 9,53

Std

270

91,80

355,60 x 323,90

12,70 x 12,70

Xs

103,50

16" x 10"

406,40 x 273,00

9,53 x 9,27

Std

305

283

95,85

406,40 x 273,00

12,70 x 12,70

Xs

144,00

16" x 12"

406,40 x 323,90

9,53 x 9,53

Std

295

99,00

406,40 x 323,90

12,70 x 12,70

Xs

147,60

16" x 14"

406,40 x 355,60

9,53 x 9,53

Std

305

305

99,00

406,40 x 355,60

12,70 x 12,70

Xs

150,30

18" x 10"

457,00 x 273,00

9,53 x 9,27

Std

343

308

116,10

457,00 x 273,00

12,70 x 12,70

Xs

138,60

18" x 12"

457,00 x 323,90

9,53 x 9,53

Std

321

121,50

457,00 x 323,90

12,70 x 12,70

Xs

147,60

18" x 14"

457,00 x 355,60

9,53 x 9,53

Std

330

121,50

457,00 x 355,60

12,70 x 12,70

Xs

171,00

18" x 16"

457,00 x 406,40

9,53 x 9,53

Std

330

121,50

457,00 x 406,40

12,70 x 12,70

Xs

171,00

20" x 10"

508,00 x 273,00

9,53 x 9,27

Std

381

333

147,15

508,00 x 273,00

12,70 x 12,70

Xs

192,60

20" x 12"

508,00 x 323,90

9,53 x 9,53

Std

346

147,15

508,00 x 323,90

12,70 x 12,70

Xs

192,60

20" x 14"

508,00 x 355,60

9,53 x 9,53

Std

356

147,15

508,00 x 355,60

12,70 x 12,70

Xs

192,60

20" x 16"

508,00 x 406,40

9,53 x 9,53

Std

356

151,20

508,00 x 406,40

12,70 x 12,70

Xs

196,20

20" x 18"

508,00 x 457,00

9,53 x 9,53

Std

368

151,20

508,00 x 457,00

12,70 x 12,70

Xs

196,20

24" x 14"

609,60 x 355,60

9,53 x 9,53

Std

432

397

155,25

609,60 x 355,60

12,70 x 12,70

Xs

220,50

24" x 16"

609,60 x 406,40

9,53 x 9,53

Std

406

188,10

609,60 x 406,40

12,70 x 12,70

Xs

234,00

24" x 18"

609,60 x 457,00

9,53 x 9,53

Std

419

188,10

609,60 x 457,00

12,70 x 12,70

Xs

234,00

24" x 20"

609,60 x 508,00

9,53 x 9,53

Std

432

198,00

609,60 x 508,00

12,70 x 12,70

Xs

252,00
