RIDUZIONI MASCHIO-FEMMINA S.W.

ANSI B16.11
6000 LBS

rid_mfsw

RIDUZIONI MASCHIO-FEMMINA S.W.

ANSI B16.11
6000 LBS

Diam. nominale

Nominal pipe size

TIPO

TYPE

M (1)

N (1)

K (1)

L (1)

mm

inches

mm

inches

mm

inches

mm

inches
1/2" x 3/8" 1 21.6 0.850 11 0.44 30 1.19 21 0.83

3/4" x 1/2"

1

26.9

1.060

12

0.47

33.5

1.31

23

0.90

3/4" x 3/8"

2

26.9

1.060

11

0.44

25.5

1.00



1" x 3/4"

1

33.6

1.325

15.5

0.61

42

1.66

26

1.03

1" x 1/2"

1

33.6

1.325

12

0.47

40

1.58

24

0.94

1" x 3/8"

3

33.6

1.325

11

0.44

28.5

1.12

7

0.28

1 1/4" x 1"

1

42.4

1.670

20.5

0.81

43

1.70

28

1.11

1 1/4" x 3/4"

1

42.4

1.670

15.5

0.61

43

1.70

28

1.11

1 1/4" x 1/2"

2

42.4

1.670

12

0.47

32

1.26



1 1/4" x 3/8"

3

42.4

1.670

11

0.44

32.5

1.28

7

0.28

1 1/2" x 1 1/4"

1

48.5

1.910

29.5

1.16

51

2.01

32

1.27

1 1/2" x 1"

1

48.5

1.910

20.5

0.81

49

1.93

28

1.11

1 1/2" x 3/4"

2

48.5

1.910

15.5

0.61

35

1.38



1 1/2" x 1/2"

3

48.5

1.910

12

0.47

39

1.53

7

0.28

2" x 1 1/2"

1

60.9

2.400

34

1.34

46

1.81

34

1.34

2" x 1 1/4"

1

60.9

2.400

29.5

1.16

47.5

1.87

34

1.34

2" x 1"

3

60.9

2.400

20.5

0.81

36

1.42

8

0.32

2" x 3/4"

3

60.9

2.400

15.5

0.61

36

1.42

8

0.32

2" x 1/2"

3

60.9

2.400

12

0.47

39

1.53

7

0.28

2 1/2" x 2"

1

73.6

2.900

43

1.70

54

2.13

36

1.42

2 1/2" x 1 1/2"

2

73.6

2.900

34

1.34

47.5

1.87



2 1/2" x 1 1/4"

3

73.6

2.900

29.5

1.16

42

1.66

8

0.32

2 1/2" x 1"

3

73.6

2.900

20.5

0.81

44

1.73

8

0.32

2 1/2" x 3/4"

3

73.6

2.900

15.5

0.61

44

1.73

8

0.32

2 1/2" x 1/2"

3

73.6

2.900

12

0.47

46.5

1.83

7

0.28

3" x 2 1/2"

1

89.6

3.530

54

2.13

63.5

2.50

38

1.50

3" x 2"

2

89.6

3.530

43

1.70

54

2.13



3" x 1 1/2"

3

89.6

3.530

34

1.34

47.5

1.87

8

0.32

3" x 1 1/4"

3

89.6

3.530

29.5

1.16

49.6

1.95

8

0.32


3" x 1"

3

89.6

3.530

20.5

0.81

48.5

1.91

8

0.32
(1) Le dimensioni non elencate nell’ANSI B16.11-1980 e BS 3799-1974 possono variare a seconda del produttore.
