if344

IF 344 PORTAGOMMA

ISO 4144

Forma:
1/8" - 1/2"   Esagono
3/4" - 2"  Ottagono
2 1/2" - 4"  Decagono

if344

IF 344 PORTAGOMMA

ISO 4144

Forma:
1/8" - 1/2"   Esagono
3/4" - 2"  Ottagono
2 1/2" - 4"  Decagono

Size mm

1/8"

1/4"

3/8"

1/2"

3/4"

1"

1 1/4"

1 1/2"

2"

2 1/2"

3"

4"

E

5.5

8

11.5

15

20.5

26

34.5

40

51

65.5

77.5

102

J

8

10.5

11

14.5

15.5

18

20.5

20.5

25

27

30

34.5

K

4

4

5

5

5.5

6

6.5

6.5

7

7

7.5

9.5

U

23

28

33

38

45

52

52

56

60

65

70

73

V

4

5

7

10.5

16

22

27.5

34.5

46

59

71

95

T

8

9

11

15

21

27

33

39.5

52

67

80

105

S

11

15

18

22

28

35

44

50

61.5

78

90

117
