CURVA SENZA SALDATURA RAGGIO= 5 D DIMA 10

ASME B16.9

rag5d

CURVA SENZA SALDATURA RAGGIO= 5 D DIMA 10

ASME B16.9

D.E. POLLICI

D.E. INCHES

Ø EST. MM X SPESS. MM

OUTS. DIAM. MM X

THICKN MM

SCH

RAGGIO radius

H

PESO TEORICO

THEORICAL WEIGHT KG

2"

60,3 x 3,91

Std

254

284

2,17

60,3 x 5,54

Xs

2,99

3"

88,9 x 3,96

20

381

426

4,96

88,9 x 5,49

Std

6,76

88,9 x 7,62

Xs

9,14

4"

114,3 x 4,37

20

508

565

9,45

114,3 x 6,02

Std

12,83

114,3 x 8,56

Xs

17,81

6"

168,3 x 4,78

20

762

846

23,07

168,3 x 7,11

Std

33,83

168,3 x 10,97

Xs

50,95

8"

219,1 x 6,35

20

1016

1126

53,17

219,1 x 7,04

30

58,76

219,1 x 8,18

Std

67,91

219,1 x 10,31

60

84,72

219,1 x 12,70

Xs

103,17

10"

273,0 x 6,35

20

1270

1407

83,30

273,0 x 7,80

30

101,77

273,0 x 9,27

Std

120,28

273,0 x 12,70

Xs

162,64

12"

323,9 x 6,35

20

1524

1688

117,04

323,9 x 8,38

30

156,10

323,9 x 9,53

Std

176,87

323,9 x 10,31

40

190,87

323,9 x 12,70

Xs

233,33

14"

355,6 x 6,35

10

1778

1956

152,75

355,6 x 7,92

20

189,66

355,6 x 9,53

Std

227,16

355,6 x 11,13

40

264,07

355,6 x 12,70

Xs

299,95

16"

406,4 x 6,35

10

2032

2235

199,96

406,4 x 7,92

20

248,42

406,4 x 9,53

Std

297,72

406,4 x 12,70

Xs

393,58
