rag3d

CURVA SENZA SALDATURA RAGGIO= 3 D DIMA 6

ASME B16.9

rag3d

CURVA SENZA SALDATURA RAGGIO= 3 D DIMA 6

ASME B16.9

D.E. POLLICI

D.E. INCHES

Ø EST. MM X SPESS. MM

OUTS. DIAM. MM X

THICKN MM

SCH

RAGGIO radius

H

PESO TEORICO

THEORICAL WEIGHT KG

2"

60,3 x 3,91

Std

152

182

1,30

60,3 x 5,54

Xs

1,79

3"

88,9 x 3,96

20

229

278

2,98

88,9 x 5,49

Std

4,06

88,9 x 7,62

Xs

5,49

4"

114,3 x 4,37

20

305

352

5,68

114,3 x 6,02

Std

7,70

114,3 x 8,56

Xs

10,69

6"

168,3 x 4,78

20

457

541

13,84

168,3 x 7,11

Std

20,29

168,3 x 10,97

Xs

30,55

8"

219,1 x 6,35

20

610

720

31,92

219,1 x 7,04

30

35,28

219,1 x 8,18

Std

40,77

219,1 x 10,31

60

50,87

219,1 x 12,70

Xs

61,94

10"

273,0 x 6,35

20

762

898

49,98

273,0 x 7,80

30

61,06

273,0 x 9,27

Std

72,17

273,0 x 12,70

Xs

97,58

12"

323,9 x 6,35

20

914

1078

71,40

323,9 x 8,38

30

93,62

323,9 x 9,53

Std

106,08

323,9 x 10,31

40

114,47

323,9 x 12,70

Xs

139,94

14"

355,6 x 6,35

10

1067

1245

91,67

355,6 x 7,92

20

113,82

355,6 x 9,53

Std

136,32

355,6 x 11,13

40

158,47

355,6 x 12,70

Xs

180,00

16"

406,4 x 6,35

10

1219

1422

119,98

406,4 x 7,92

20

149,03

406,4 x 9,53

Std

178,60

406,4 x 12,70

Xs

236,11
