curvsal90

CURVE SENZA SALDATURA 90° RAGGIO= 1 D DIMA 2

ASME B16.9 ASTM A 403
WP 304/304L AND WP 316/316L

Su richiesta saldate

curvsal90

CURVE SENZA SALDATURA 90° RAGGIO= 1 D DIMA 2

ASME B16.9 ASTM A 403
WP 304/304L AND WP 316/316L

Su richiesta saldate

D.E. POLLICI

D.E. INCHES

Ø est. mm x Spess. mm

Outs. diam. mm x Thckn mm

SCH

A

Peso Kg/pz.

Weight Kg/pcs.

1"

33.40 x 2.77

10S

25

0.10

33.40 x 3.38

40S

0.12

33.40 x 4.55

80S

0.13

1 1/4"

42.16 x 3.56

40s

32

0.20

42.16 x 4.85

80s

0.22

1 1/2"

48.26 x 2.77

10S

38

0.22

48.26 x 3.68

40S

0.29

48.26 x 5.08

80S

0.32

2"

60.33 x 2.77

10S

51

0.37

60.33 x 3.91

40S

0.51

60.33 x 5.54

80S

0.60

2 1/2"

73.03 x 3.05

10S

64

0.62

73.03 x 5.16

40S

1.02

73.03 x 7.01

80S

1.14

3"

88.90 x 3.05

10S

76

0.98

88.90 x 5.49

40S

1.50

88.90 x 7.62

80S

1.85

4"

114.30 x 3.05

10S

102

1.72

114.30 x 6.02

40S

3.12

114.30 x 8.56

80S

3.56

5"

141.30 x 3.40

10S

127

2.78

141.30 x 6.55

40S

5.28

6"

168.28 x 3.40

10S

152

4.15

168.28 x 7.11

40S

7.15

168.28 x 10.97

80S

11.79

8"

219.08 x 3.76

10S

203

8.00

219.08 x 8.18

40S

17.05

10"

273.05 x 4.19

10S

254

12.40

273.05 x 9.27

40S

24.00

12"

323.85 x 4.57

10S

305

17.20

323.85 x 9.53

40S

38.10

14"

355.60 x 4.78

10S

356

23.59

355.60 x 9.78

40S

45.40

16"

406.40 x 4.78

10S

406

30.84

406.40 x 9.53

40S

59.40

18"

457.20 x 4.78

10S

457

39.50

20"

508.00 x 5.54

10S

508

65.00

24"

609.60 x 6.35

10S

610

92.00
